CNC V GROOVING MACHINE

CONTROL SYSTEM AND MAIN PARTS

No.ProductSize
1 Machining Thickness of Sheet 0.6 - 4 / 6mm
2 Machining Length of Sheet 3200 / 4000 / 4500mm
3 Machining Width of Sheet 1500mm
4 Cutting Speed 15 - 60 m/min
5 Single Blade Cutting Area 2.25㎡
6 Feeding Speed 2 - 10 m/min
7 Y Axis Minimum Setting Unit 0.01 mm
8 Y Axis Minimum Positioning Accuracy ±0.05 mm
9 Z Axis Minimum Setting Unit 0.01mm
10 Z Axis Minimum Positioning Accuracy ±0.03mm
11 X Axis Variable Frequency Motor Power 4Kw
12 Y Axis Servo Motor Power 1Kw
13 Z Axis Servo Motor Power 1Kw
14 Air Source Pressure 0.4 - 0.6 MPa
15 Overall Size 5600mm*2200mm*2100mm
16 Weight 10 Ton -11 Ton

CONTROL SYSTEM AND MAIN PARTS

NoProductFeatures
1 High Precision Ball Screw HIWIN Taiwan
2 Angular Contact Bearing NSK Japan
3 Electrical Components Schneider, France
4 Alloy Blade Troy, South Korea
5 Touch Screen Chi Me Taiwan
6 Pneumatic Component Airtec / WUXI HUATONG
7 Proximity Switch Iskate
8 Precision Linear Guide HIWIN Taiwan
9 Machine Power Cable Henggong Shanghai
